First choice for all around cooling.
Suitable for places with wide ceiling head like offices spaces. It has a selectable airflow pattern, and a 360 degree round flow air reach. Each louver can be controlled individually.
MODEL: FCF50/60/71/100/125/140CVM
CAPACITY:2 HP / 2.5 HP / 3 HP / 4 HP / 5 HP / 6 HP
REFRIGERANT: R32
Here's the pricelist:
CEILING CASSETTE TYPE (INVERTER):
3.0hp (FCFC71AXVL/RZFC71AVM) = 116,900 SRP
4.0hp (FCFC100AXVL/RZFC100AVM) = 147,700 SRP
6.0hp (FCFC140AXVL/RZFC140AVM) = 186,400 SRP
Features
All Around Cooling
•Selectable Airflow Pattern: 360 Airflow/Circulation Airflow and Individual Airflow Direction Control.
Easy Maintenance
• With Ultra long-life filters (option), maintenance is not required in normal shops or offices for up to four years
Optimal Comfort and Convenience
• Suitable for high ceilings with two selectable temperature-sensors and 3 discharge modes.
Daikin Advantage
Circulation Airflow
Cools the entire room to deliver comfort that never feels cold.
2-way horizontal flow
4-way swing flow
2-way horizontal flow (direction changes)
4-way swing flow
Individual Airflow Direction Control
Airflow direction can be individually adjusted for each air discharge outlet to deliver optimal air distribution that conforms to conditions for airflow direction (small and large loads). Selectable from position 0 to 4, swing, and no individual setting.
Selectable Airflow Pattern
Because air flows out from corner outlets, comfort spreads more widely
Technical Specifications
Temperature Control by Inverter and Non-Inverter Compressors (Cooling)
|
Model Name |
FCF50CVM |
FCF60CVM |
FCF71CVM |
FCF100CVM |
FCF125CVM |
FCF140CVM |
|
Cooling Capacity |
5.0 (2.3-5.6) kW |
6.0 (2.6-6.3) kW |
7.1 (3.2-8.0) kW |
10.0 (5.0-11.2) kW |
12.5 (5.7-14.0) kW |
14.0 (6.2-15.5) kW |
|
Power Consumption |
1.14 kW |
1.53 kW |
1.93 kW |
2.97 kW |
4.18 kW |
5.47 kW |
|
Dimensions (HxWxD) |
256mm x 840mm x 840mm |
256mm x 840mm x 840mm |
256mm x 840mm x 840mm |
298mm x 840mm x 840mm |
298mm x 840mm x 840mm |
298mm x 840mm x 840mm |
